F2 X86 N3350/N4200/J4205 HDMI+DP 3LAN 1SD 4COM 4USB Modular Fanless Mini PC Wide Temp IPC RouterOS

Contact Now* Send an Inquiry to this supplier.
or
Start Order * Name your price

Contact us

Future Robot Technology Co., LTD
[China]

Address
Room 406 Block A South Wind Tower, Nanshan Cloud Valley Innovation Industry Park, No 4093 Lau Sin Av Shenzhen Guangdong
Phone
86-755-86560716
Contact name
Lynn XU

Quick Information

  • Brand Name: FutureRobot
  • Place of Origin: China
  • Model Number : F2
  • :

Description

Feature:

- Intel Apollo Lake N3350/N4200/J4205 series SoC
- Dual independent display: HDMI + DP
- 3 x Gigabit LAN(2 x intel i210)
- 1 x Mini-PCIe expansion for WiFi and 4G module

- 1 x USIM for 3G/4G LTE communication
- 1 x M.2 and 1 x 2.5" SATA storage device
- 2 x RS232,2 x RS485 Serial Ports
- Wide Temperature operation -20ºC~60ºC
- Aluminum Alloy Enclosure
- Fanless slim system, Wall mounting design
- Through PCIe/USB/SPI/I2C/LPC/FPGA signal conversion to achieve rapid customization



Specifications:

Onboard CPUIntel Apollo Lake N3350/N4200/J4205 series SoC
Onboard MemoryDDR3L 1600 MHz
Capacity - 2GB (up to 8GB)
DisplayChipset - Intel®HD Graphics 505
DP Max. 4096 x 2304 60Hz
HDMI Max. 4096 x 2304 24Hz
Dual Display - HDMI + DP
AudioController Realtek ALC662, High Definition Audio. Line-out, Mic-in
EthernetRTL8111H GbE, support Wake On Lan
Intel i210 GbE, support Wake On Lan
Front Panel Connectors2 x USB3.0 Port
1 x Mic-in
1 x Line-out
1 x TF-Card
1 x Clean CMOS
1 x Power button
2 x RS232 Port
2 x GbE Port
Rear Panel Connectors1 x GbE Port
1 x HDMI
1 x DP Port
2 x USB2.0 Ports
1 x 12V~32V DC IN
2 x RS485 Port
Expansion1 x Full Size for WLAN or WWAN module
1 x USIM for 3G/4G LTE communication
StorageeMMC 8GB up to 256GB
1 x M.2 2242 SSD
1 x TF Card
1 x SATA3.0 for 2.5" hard disk
Power Supply12~32V
OSWindows 10 64Bit, Linux
Physical CharacteristicsDimensions 120 x 100 x 51mm (LxWxH)
Weight 0.65 Kg
EnvironmentOperating Temperature -20ºC~60ºC,airflow 0.7m/s
Storage Temperature -40ºC~80ºC
Relative Humidity 95% 40ºC ( Non-Condensing)
Vibration During Operation - With SSD:3Grms,IEC 60068-2-64,random vibration,5~500 Hz,1hr/axis
Shock During Operation - With SSD:30G, IEC 60068-2-27, half sine, 11m duration
ESD Contact +/-4 KV, Air +/-8 KV
CertificationCE/FCC/RoHS



Application

F2 is intelligent and powerful embedded computer, through PCIe/USB/SPI/I2C/LPC/FPGA signal conversion to achieve rapid customization and supportive for broad application development and easy deployment, it performs great in ITS, Facility Management, Industrial Automation, Smart Warehousing, Machine Vision and IoT applications.



Ordering Information




P/NDescription
F2-100Intel Celeron N3350 2.4G, 2GB DDR3L ,32G eMMC,3xLAN,4xUSB,4xCOM,12-32V DC
F2-200Intel Pentium N4200 2.5G, 4GB DDR3L ,64G eMMC,3xLAN,4xUSB,4xCOM,12-32V DC
F2-300Intel Pentium N4200 2.5G, 4GB DDR3L ,128G eMMC,3xLAN,4xUSB,4xCOM,12-32V DC
F2-400Intel PentiumJ4205  2.6G, 4GB DDR3L ,64G eMMC,3xLAN,4xUSB,4xCOM,12-32V DC
F2-500Intel Pentium J4205  2.6G, 4GB DDR3L ,128G eMMC,3xLAN,4xUSB,4xCOM,12-32V DC


*We have customization service on F2, please let us know your specific needs and application.



Packing List

1 x F2 Unit
1 x User Manual
1 x 3PIN Phoenix
1 x Certificate of Approval


Optional Item for Default SKU

AC-DC Adapter, DC12V/2A 24W


About us

Future Robot Technology Co., Limited is professional manufacturer of Industrial Fanless Embedded Computer, Smart Camera, Motion Controller and 4-port PoE Frame Grabber, 4-port USB3.1 Expansion card etc., we have hardware, software and structure engineer team with more than 15years experience.
As member of Intel® IoT Solutions Alliance and partner of Intel® IoT RFP Ready Kits, we aim to provide reliable, high efficient and cost-effective hardware and system solutions for customers worldwide.
Our products pass CE/FCC/RoHS tests and you can check on certifications in our profile center.


Customization Service:

Basically 8 steps on customizing services
1. Confirmation of customers specific requirement
2. Product proposal base on customers' specific application
3. Evaluation of project feasibility
4. Implement projects into R&D process
5. Sample confirmation and test
6. Trail-produce of small QTY
7. Mass-production confirmation as settled sample standard
8. Delivery of products


FAQ:

Q : Are you a manufacturer? How can I know more about you?
A : Yes, Future Robot Technology Co., Limited is professional manufacturer of Industrial Fanless Embedded Computer, Smart Camera, Motion Controller and 4-port PoE Frame Grabber, 4-port USB3.1 Expansion card etc., we have hardware, software and structure engineer team with more than 15years experience.
As member of Intel® IoT Solutions Alliance, we aim to provide reliable, high efficient and cost-effective hardware and system solutions for customers worldwide. We are also Intel® IoT RFP Ready Kits supplier.

Q : What is the lead-time for my order?
A : Usually 1-3 days for stock products and 7-10 days for bulk order. All of our products have passed the QC Test before delivery.

Q : What is the MOQ?
A : MOQ is 1 unit.

Q : What is the warranty policy?
A : One year warranty.

Q : Which kind of certificates do you have?
A : CE, FCC, ROHS

Q : Can you provide OEM service?
A : Yes, we do provide OEM service.

Q: Do you have customization service?
A: We have powerful technical team, hardware, software and structure engineers with more than 15years rich experiences, to support on customer specific application.


Certificates

  • CE : CTL1901179012EC
  • FCC : CTL1901179012FC

Price

  • Delivery Port : Shenzhen

Packaging & Delivery

  • Packing :BOX
  • Packaging Size : 120 x 100 x 51  Millimeters
  • Package Weight : 0.65
  • Delivery Lead Time : 7-15days general leadtime, 1-3days for ready goods
  • Supply Ability : 20,000 Sets per Month

Product Image

  • 1F2 X86 N3350/N4200/J4205 HDMI+DP 3LAN 1SD 4COM 4USB Modular Fanless Mini PC Wide Temp IPC RouterOS image 1
  • 2 F2 X86 N3350/N4200/J4205 HDMI+DP 3LAN 1SD 4COM 4USB Modular Fanless Mini PC Wide Temp IPC RouterOS image 2
  • 3 F2 X86 N3350/N4200/J4205 HDMI+DP 3LAN 1SD 4COM 4USB Modular Fanless Mini PC Wide Temp IPC RouterOS image 3
  • 4 F2 X86 N3350/N4200/J4205 HDMI+DP 3LAN 1SD 4COM 4USB Modular Fanless Mini PC Wide Temp IPC RouterOS image 4
